Our auto 5-part Hematology Analyzer VH50 for veterinary use only.
Results 36 parameters+4 scattergrams of WBC +2 histogram in 60 seconds for better diagnosis.
19 species available and the reference range and support customize species.
Smart counting
Description
Assays:
36 parameters:WBC, Lym%, Mon%, Neu%, Bas%, Eos%, Lym#, Mon#, Neu#, Eos#, Bas#, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW-CV, PDW-SD, PCT, P-LCR, P-LCC, NLR, PLR.
ALY%, ALY#, LIC%, LIC#, NRBC%, NRBC#, PLT Clumps%, PLT Clumps# (RUO)
Features:
REAL 5-diff hematology analyzer
60 samples per hour
Tri-angle Laser scattering and sheath flow for WBC differentiation and counting
36 parameters + 4 scattergrams + 2 histograms
Sample mode:Whole blood, pre-diluted
20μl whole blood
Built-in 10.4-inch TFT touch screen
Support 19 Species
Cat, Dog, Rabbit, Sheep, Goat, Cattle, Horse, Rat, Mouse, Llama, Deer, Musk deer, Monkey, Tiger, Dolphin, Pig, Camel, Ferret, Panda.
Smart Counting Mode with better repeatability for low WBC / PLT value samples.
Specifications:
4 scattergrams for WBC differential
Throughput:60 samples per hour
Calibration:Manual and auto calibration
Quality control:3 level QC, LJ graph, XB graph
Reagents:
3 Reagent (2 Lyse + 1 Diluent)
1 Probe cleanser for maintenance
All-in-one Solution:
Built-in printer
Built-in barcode scanner (optional)
Built-in card reader
Interface:
4 USB ports, 1 LAN port
HL7 protocol, support LIS
Storage:
60,000 sample results with scatter-grams and histograms
Power:
AC 100-240V, 50/60±1Hz
Dimension
430mm×350mm×435mm (L×W×H)
Weight
28KG
