• X-ray generation
X-ray generator - Rotating anode tube with active heat management - X-ray tube - Monoblock 78,125 kHz high-frequency, micro-processor controlled generator
Nominal power - 15 kW:120 kV, 125 mA
• Imaging chain
Image Intensifier - Triple-mode 9" HRC / Triple-mode 12" GG - TV camera type - CCD, high resolution 1K²
Constant beam filtration - Integrated beam filter: 1.0 mm Al. + 0.1 mm Cu - Nominal II formats - 23, 17, and 13 cm (9", 7", and 5") / 31, 23, and 17 cm (12", 9", and 7")
Image processing - ✓ - Stand monitor - 15" LCD monitor on the C-arm gives a whole new level of simplicity
• Connectivity
Video in - S-Video, DVI (digital and analog), SDI - Analog video out - ✓
Digital video out (optional) - 2 DVI connectors left and right monitor - USB storage - PNG, MP4, BMP
Advanced DICOM/IHE package (optional) - Modality Worklist Management, Modality Performed Procedure Step Storage Commit, Full compliance to the IHE Scheduled Workflow Integration profile
