- REAL optical 3D 4K technology: dual-channel 4K optical signal acquisitior
dual 1/1.8 super CMOS,with pixel fusion technology.
- Brand: Shrek
- Product Type: Medical Endoscope Camera
- Warranty: Five years
Description :
1. Dual-lens optical path design: Utilizing independent dual optical channels (e.g., parallel or converging optical paths), the system simulates the human eye's interpupillary distance (adjustable from 55-75mm), achieving native stereoscopic imaging through physical light splitting rather than electronic synthesis.
2. Zero-delay parallax synchronization: Dual CMOS sensors capture images in strict synchronization, eliminating image misalignment associated with electronic 3D and ensuring spatial and temporal consistency between left and right eye images.
Parameter :
- lmage Sensor : 1/1.8 CMOS Sony Color Super HAD CMOS
- Video output : USB、VGA、HDMI、RS232
- Effective pixels : ≥3840x2160pixel
- Scanning Frequency : N:60HZ P:60HZ
- Scan mode : Progressive scan
- Horizontal resolution : >2300 lines
- Electronic shutter : AWC/MWC(1/5(60)~1/60.00s)
- Digital Zoom : 0-60x
- DNR : 3D Denoise
- SNR : ≥50dB
- Brightness : ODS adjustable
- White balance : AWC/MWC/One step WB
- Min illumination : F1.2≤0.1lux
- DSS : 30x
- Fuse : F1AL 250V AC
