- (Automatic Sliding Door type)
Specifications :
- Model :
HS-5025PT
- Style :
1. Single Door type :
- Overall Dimension :
W872 x D1,300 x H1,801 ㎜
- Loading System :
Loading Car:W460 x D950 x H400 ㎜
Carriage:W480 x D1,464x H1,123 ㎜
Loading Car & Carriage; 1set
Loading Car Shelf:W446x D926 x H26 ㎜, 3ea
- Weight :
Unit:710 ㎏, Loading Car: 22㎏
2. Double Door type
- Overall Dimension :
W872 x D1,350 x H1,838 ㎜
- Loading System :
Loading Car:W460 x D950 x H400 ㎜
Carriage:W480 x D1,453x H1,123 ㎜
Loading Car; 1ea, Carriage; 2ea
- Weight :
Unit:860 ㎏, Loading Car: 22 ㎏
- Chamber :
W500 x D1,000 x H500 ㎜, Vol: 250ℓ, Material: STS 316L
- Operating Temperature Range :
121.0℃ ~ 135.0℃
- Air Removal :
Vacuum / Gravity
- Controls :
Microprocessor
- Display :
Touch Screen type Color LCD
- Printer :
Direct Thermal Printing, Printing Paper Roll; W58 x Ø40mm
- Power Source :
Built-in Steam Generator:AC 230V, 3phase 3wire, 50/60㎐, 55A or
AC 380V, 3phase 4wire, 50/60㎐, 32A
Use external steam:AC 230V, 50/60㎐, 5A
- Steam Source :
Built-in Steam Generator:Heater 20㎾, water Pump
External Steam System:Saturated Steam of 97% Dryness,
Pressure:3.50bar~5.00bar, Flow Rate: max. 50㎏/hr
- Water Source :
Pressure:2.10~5.00bar, Flow Rate: max. 50 ℓ/min
- Vacuum System :
Water Ejector, Water Pump
- Option :
Water Saving Device / Cooling Device
- Environment Condition :
* Altitudes up to 2,000 meters.
* Temperature range of +5℃ to +40℃.
* Maximum relative humidity of 80% for temperatures up to 31℃, decreasing linearly to 50% at 40℃.
* Main supply voltage fluctuation of ±10% of nominal.
* Installation Category (Overvoltage Category) Ⅱ, Pollution Degree 2.
